Vertical Circulation Heater

Circulation heaters are the perfect solution for generating heat and enhancing normal immersion heaters performance. They are designed to heat pressurized circulating fluids to provide effective, controlled heating to water, oil, steam and other gases.

Send Inquiry

High Efficient Compact heating vertical Lubrication oil circulation heater

Flanged immersion heaters

circulating heater
Model	XL-600-690/191-3	Power(KW)	191
Voltage(V)	690	Wiring Form	Y型
Frequency(Hz)	50/60	Cold Insulation Resistance(Ω)	≥5
Wiring Group	3	Over-temperature Protection Switch (yes/no)	thermocouple
Total Current(A)	159.82	Per Group Current(A)	53.27
Interphase Resistance(Ω)	14.96	Surface Load(W/cm²)	1.47
Heating Medium	lubricating oil	Material of Heating Tube	S30408
Standard of Flange	HG/T 20592-2009 DN600 PN25	Material of Flange	S30408
Design Pressure(Mpa)	1.6	Operating Pressure(Mpa)	1.6
Design Tempreture(℃)	100	Operating temperature(℃)	50
Protection Grade	IP55	Explosion-proof Grade	/
Design Standards	JB/T 2379-2016	Heating Tube Diameter(mm)	16
Length of Heating Tubes Under The Flange(mm)	1050	Cold Zone Length of Heating Tubes Under The Flange(mm)	200
Center Distance of Heating Tube(mm)	50	Quantity of Heating Tubes(支)	150
Product Dimensions For Reference(mm)	17501150950	Weight For Reference(KG)	/
