Product Introduction
China Manufacturer Industrial Horizontal regeneration heater for DIW DI water deionized water
| circulating heater | |||
| Model | XL-125-380/20-1 | Power(KW) | 20 |
| Voltage(V) | 380 | Wiring Form | 0 |
| Frequency(Hz) | 50/60 | Cold Insulation Resistance(Ω) | ≥5 |
| Wiring Group | 1 | Over-temperature Protection Switch (yes/no) | yes |
| Total Current(A) | 30.39 | Per Group Current(A) | 30.39 |
| Interphase Resistance(Ω) | 14.44 | Surface Load(W/cm²) | 3.63 |
| Heating Medium | water | Material of Heating Tube | S30408 |
| Standard of Flange | HG/T 20592-2009 DN125 PN16 | Material of Flange | S30408 |
| Design Pressure(Mpa) | 1.6 | Operating Pressure(Mpa) | 1.6 |
| Design Tempreture(℃) | 100 | Operating temperature(℃) | 80 |
| Protection Grade | IP54 | Explosion-proof Grade | / |
| Design Standards | JB/T 2379-2016 | Heating Tube Diameter(mm) | 12 |
| Length of Heating Tubes Under The Flange(mm) | 1000 | Cold Zone Length of Heating Tubes Under The Flange(mm) | 200 |
| Center Distance of Heating Tube(mm) | 40 | Quantity of Heating Tubes(piece) | 9 |
| Product Dimensions For Reference(mm) | 1250*26*260 | Weight For Reference(KG) | 25 |
